Configure your solution to your needs with our standardized modules

The MD10-L diaphragm compressor unit is ideal for hydrogen refueling stations with medium to high demand.

We deliver the unit preinstalled and pretested in a standardized container, complete with all necessary accessories, including a certified ATEX zone and an optional PLC. Ready to connect to your prepared connection points, it ensures a seamless, efficient, and scalable setup. With minimal project management and engineering effort, it truly is a plug-and-play kit, designed to meet the demands of your refueling operations.


Your benefits

  • Minimum effort on site
    Our standardized turn-key solution, tailored with optional modules to meet your specific needs, is ready to be connected to your refueling station.
  • Low risk investment
    The MD10-L containerized solution is delivered fully installed and pretested with hydrogen at our packaging facility, ensuring reliability and performance.
  • Scalability
    Easily add additional compression units in the future to expand your refueling station capabilities during the energy transition.
  • Comprehensive after-sales support
    Our extensive service-center network is at your service throughout the entire lifetime of the product, ensuring continuous support.

Features

  • Compress ~45 kg/h hydrogen
  • Discharge pressure up to 550 bar
  • Container designed for effortless maintenance

Get in touch

Talk to our specialists.

Contact us

Compressors

Downloads

Technical data

Type MD 10-L 500/30-550 MD 10-L 500/30-550
Pa barg 25-30 34-40
Rated power  kW / hp 81 / 109 78 / 106
Pd barg 300-550 300-550
Mass flow Nm/ h / kg / h 500 / 45 500 / 45
Motor  v-belt  drive  v / hz / rpm 400 / 50 / 1'450 498 400 / 50 / 1'450 498
Dimenssion l x w x h  mm / In 6'050 x 2'430 x 3'250 6'050 x 2'430 x 3'250
Weight  t 25 25
